Movex MX 828 K330 – P11020303
Movex MX 828 K330 – P11020303
Series: 828 FT
Brand: Movex – Italy
Basic Features
- Pitch: 38.1mm
- Thickness:: 4mm
- Width: 83.8mm
- Surface Type: FT – Flat Top
- Functionality: Straight
- Temperature range dry: -40÷120 °C
- Box: 10 FT – 3.048m/box
Request a quote
Contact MHP at 0909 840 002 for consultation and quotation!
- Nationwide Delivery
- Technical Waranty
Technical features
| Product name | Movex MX 828 K330 |
| Series | 828 FT (Flat Top) |
| Bước xích (Pitch) | 38.1 mm |
| Thickness | 4 mm |
| Surface Type | FT – Flat Top |
| Functionality | Straight |
| Unit of measure | Meter |
| Width | K330 – 83,8 mm |
| Material | MX – Performance PBT (03) |
| Part | P11020303 |
| Back flex radius | 50 mm |
| Mass | 1.13 kg/m |
| Pin material | Stainless steel |
| Box | 10 ft – 3.048 m |
| Max working load | 1860 N |
